Receive a Fujistu $400 pre paid Visa card when you purchase this eligible Fujitsu air conditioner via redemption only. Promotion is between 01/03/2016 and 31/07/2016. To claim and for full terms and conditions click here.

One outdoor unit can be connected to a wide variety of indoor units including wall mounted consoles cassette and ducted units. Each room can be individually controlled allowing you to set different temperatures in each room helping save running costs by heating or cooling rooms as required. System settings allow you to save energy helping reduce power costs

Features

  • 8kW Cooling
  • 9.6kW Heating
  • Inverter Multi 3/4 Room
  • Auto Restart
  • ALL DC
  • Blue Fin Heat Exchanger
  • Auto-Changeover

Specifications

  • Reverse Cycle System Yes
  • Cooling Capacity (Watts) 8 000
  • Cooling Capacity (BTU/h) 27 300
  • Range (Watts) 3 500-10 100
  • Range (BTU/h) 11 940-34 500
  • Heating Capacity (Watts) 9 600
  • Heating Capacity (BTU/h) 32 800
  • Range (Watts) 3 700-12 000
  • Range (BTU/h) 12 620-41 000
  • Power Supply (Volts) 240
  • Phase-Frequency (Ph - Hz) 1-50
  • Power Supply Attachment Outdoor
  • Plug Size (If Applicable) N/A
  • Running Current Cooling (Amps) 9.3
  • Running Current Range (Amps) Max 15.0
  • Input Cooling (Watts) 2 220
  • Input Range (Watts) Max 3 560
  • Running Current Heating (Amps) 10.1
  • Running Current Range (Amps) Max 15.0
  • Input Heating (Watts) 2 400
  • Input Range (Watts) Max 3 580
  • E.E.R. - Cooling 3.6
  • C.O.P. - Heating 4
  • Fan Speed 2
  • Compressor Type Twin Rotary
  • O.U. Sound Pressure Level (dBA@1mtr) 50
  • O.U. Sound Power Level (dBA) 64
  • Refrigerant Type R410A
  • Connection Pipe Sizes Gas (mm) 2 x 9.52 2 x 12.7
  • Connection Pipe Sizes Liquid (mm) 4 x 6.35
  • Pre Charged Length (Metre) 50
  • Minimum Pipe Length (Metre) 20
  • Maximum Pipe Length (Metre) 25
  • Maximum Pipe Height (Metre) 70
  • Pipe Connection Methods Flare
  • Outdoor operating Temp Cooling Degrees C 0 to 46
  • Outdoor operating Temp Heating Degrees C -10 to 24

Dimensions

  • W 900 x H 830 x D x 330

(AOTG30LBTA4)

SKU AOTG30LBTA4
Brand Fujitsu
Color
